RL78/F13, F14 CHAPTER 36 ELECTRICAL SPECIFICATIONS (GRADE Y)

R01UH0368EJ0210 Rev.2.10 1822

Dec 10, 2015

36.5.3 On-chip Debug (UART)

(TA = -40 to +150C, 2.7 V  EVDD0 = EVDD1 = VDD  5.5 V, VSS = EVSS0 = EVSS1 = 0 V)

Parameter Symbol Conditions MIN. TYP. MAX. Unit

Transfer rate - 115.2 k 1 M bps

36.5.4 LIN/UART Module (RLIN3) UART Mode

A = -40 to +150C, 2.7 V  EVDD0 = EVDD1 = VDD  5.5 V, VSS = EVSS0 = EVSS1 = 0 V)

Parameter Symbol Conditions MIN. TYP. MAX. Unit

Transfer rate -

Operation mode,

HALT mode

LIN communication clock source

CLK or fMX):

4 to 24 MHz

4000 kbps

SNOOZE mode

LIN communication clock source

CLK):

1 to 24 MHz

FRQSEL4 = 0 in the user option

byte (000C2H/020C2H)

4.8

LIN communication clock source

CLK):

1 to 24 MHz

FRQSEL4 = 1 in the user option

byte (000C2H/020C2H)

2.4
