RL78/F13, F14 CHAPTER 18 CAN INTERFACE (RS-CAN LITE)

R01UH0368EJ0210 Rev.2.10 1301

Dec 10, 2015

18.3.10 CAN Global Configuration Register H (GCFGH)

Address GCFGHL: F0324H, GCFGHH: F0325H

b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0

ITRCP[15:0]

After Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Bit Symbol Bit Name Description R/W

15-0 ITRCP[15:0] Interval Timer Prescaler Set If the set value is M, fCLK/2 is frequency-divided by M.

Setting H'0000 is prohibited, when the interval timer

is in use.

R/W

Modify the GCFGH register only in global reset mode.

• ITRCP[15:0] Bits

These bits are used to set a clock source division value of the interval timer for FIFO buffers. For details, see

18.6.3 (1) Interval Transmission Function.
