RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS
R01UH0368EJ0210 Rev.2.10 349
Dec 10, 2015
4.5 Settings of Port Mode Register and Output Latch When Using Alternate Function
To use the alternate function of a port pin, set the port mode register, and output latch as shown in Table 4-29.
Table 4-29. Settings of Port Mode Register and Output Latch When Using Alternate Function (1/8)
Pin Name
Alternate Function
PIORXX POMXX PMCXX PMXX PXX PIMXX PITHLXX
Function Name I/O
P00 INTP9 Input 0 – – 1 × – –
(TI05) Input 1 – – 1 × – –
(TO05) Output 1 – – 0 0 – –
P01 (TI04) Input 1 – – 1 × – –
(TO04) Output 1 – – 0 0 – –
P02 (TI06) Input 1 – – 1 × – –
(TO06) Output 1 – – 0 0 – –
P03 (RTC1HZ) Output 1 – – 0 0 – –
P10 TI13 Input 0 × – 1 × 0 0/1
TO13 Output 0 0 – 0 0 × ×
TRJO0 Output × 0 – 0 0 × ×
SCK10 Input 0 × – 1 × 0/1 0/1
Output 0 0/1 – 0 1 × ×
SCL10 Output 0 0/1 – 0 1 × ×
LTXD1 Output 0 0 – 0 1 × ×
CTXD0 Output 0 0 – 0 1 × ×
P11 TI12 Input 0 × – 1 × 0 0/1
SI10 Input 0 × – 1 × 0/1 0/1
TO12 Output 0 0 – 0 0 × ×
SDA10 I/O 0 1 – 0 1 0/1 0/1
RXD1 Input 0 × – 1 × 0/1 0/1
LRXD1 Input 0 × – 1 × 0 0/1
CRXD0 Input 0 × – 1 × 0 0/1
(TRDIOB0) Input 1 × – 1 × 0 0/1
Output 1 0 – 0 0 × ×
Remarks 1. : Don't care
PIORxx: Peripheral I/O redirection register
POMxx: Port output mode register
PMCxx: Port mode control register
PMxx: Port mode register
Pxx: Port output latch
2. The relationship between pins and their alternate functions shown in this table indicates the relationship
when a 100-pin product is used. In other products, alternate functions might be assigned to different
pins, but even in this case, the PIORxx, POMxx, PMCxx, PMxx, and Pxx set in the same way.
3. Functions in parentheses in the above table can be assigned via settings in the peripheral I/O
redirection register (PIOR).
(The notes are described after the last table.)
