RL78/F13, F14 CHAPTER 15 SERIAL ARRAY UNIT
R01UH0368EJ0210 Rev.2.10 960
Dec 10, 2015
UART performs the following four types of communication operations.
• UART transmission (See 15.7.1 UART transmission.)
• UART reception (See 15.7.2 UART reception.)
• LIN transmission (UART0 only) (See 15.8.1 LIN transmission.)
• LIN reception (UART0 only) (See 15.8.2 LIN reception.)
15.7.1 UART transmission
UART transmission is an operation to transmit data from this MCU to another device asynchronously (start-stop
synchronization).
Of two channels used for UART, the even channel is used for UART transmission.
UART UART0 UART1
Target channel Channel 0 of SAU0 Channel 2 of SAU0
Pins used TxD0 TxD1
Interrupt INTST0 INTST1
Transfer end interrupt (in single-transfer mode) or buffer empty interrupt (in continuous transfer mode)
can be selected.
Error detection flag None
Transfer data length 7 to 9 or 16 bits
Transfer rate Max. fMCK/6 [bps] (SDRmn [15:9] = 2 or more), Min. fCLK/(2 × 2
15
× 128) [bps]
Note
Data phase Forward output (default: high level)
Reverse output (default: low level)
Parity bit The following selectable
• No parity bit
• Appending 0 parity
• Appending even parity
• Appending odd parity
Stop bit The following selectable
• Appending 1 bit
• Appending 2 bits
Data direction MSB or LSB first
Note Use this operation within a range that satisfies the conditions above and the AC characteristics in the electrical
specifications.
Remarks 1. f
MCK: Operation clock frequency of target channel
f
CLK: System clock frequency
2. m: Unit number (m = 0, 1), n: Channel number (n = 01), mn = 00, 10
