RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS
R01UH0368EJ0210 Rev.2.10 337
Dec 10, 2015
4.3.15 Peripheral I/O redirection register 6 (PIOR6)
This register is used to specify whether to enable or disable the peripheral I/O redirect function.
PIOR6 enables or disables redirection of the SNOOZE status output functions; that is, it specifies which I/O port is
assigned to each SNOOZE status output pin.
This register can be set by an 8-bit memory manipulation instruction.
After reset cancellation, this register can always be read or written to.
Any reset source clears this register to 00H.
Figure 4-88. Format of Peripheral I/O Redirection Register 6 (PIOR6)
Address: F001CH After reset: 00H R/W
Symbol 7 6 5 4 3 2 1 0
PIOR6 PIOR67 PIOR66 PIOR65 PIOR64 PIOR63 PIOR62 PIOR61 PIOR60
Bit Function 100-pin 80-pin
Setting value Setting value
0 1 0 1
PIOR67 SNZOUT7 P73 P154 P73 
PIOR66 SNZOUT6 P72 P155 P72 
PIOR65 SNZOUT5 P71 P156 P71 
PIOR64 SNZOUT4 P70 P157 P70 
PIOR63 SNZOUT3 P12 P64 P12 P64
PIOR62 SNZOUT2 P41 P65 P41 P65
PIOR61 SNZOUT1 P125 P56 P125 P56
PIOR60 SNZOUT0 P30 P57 P30 P57
Caution The 64-, 48-, 32-, 30-, and 20-pin products do not have the PIOR6 register.
