RL78/F13, F14 CHAPTER 18 CAN INTERFACE (RS-CAN LITE)
R01UH0368EJ0210 Rev.2.10 1302
Dec 10, 2015
18.3.11 CAN Global Control Register L (GCTRL)
Address GCTRLL: F0326H, GCTRLH: F0327H
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
— — — — — THL
EIE
MEIE DEIE — — — — — GS
LPR
GMDC[1:0]
After Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 1
Bit Symbol Bit Name Description R/W
15 to
11
Reserved These bits are always read as 0. The write value should
always be 0.
R
10 THLEIE Transmit History Buffer Overflow
Interrupt Enable
0: Transmit history buffer overflow interrupt is disabled.
1: Transmit history buffer overflow interrupt is enabled.
R/W
9 MEIE FIFO Message Lost Interrupt Enable 0: FIFO message lost interrupt is disabled.
1: FIFO message lost interrupt is enabled.
R/W
8 DEIE DLC Error Interrupt Enable 0: DLC error interrupt is disabled.
1: DLC error interrupt is enabled.
R/W
7 to 3 Reserved These bits are always read as 0. The write value should
always be 0.
R
2 GSLPR Global Stop Mode 0: Other than global stop mode
1: Global stop mode
R/W
1, 0 GMDC[1:0] Global Mode Select
b1 b0
0 0 : Global operating mode
0 1 : Global reset mode
1 0 : Global test mode
1 1 : Setting prohibited
R/W
THLEIE Bit
When the THLEIE bit is set to 1 and the THLES flag in the GERFLL register is set to 1, an interrupt request is
generated. Modify this bit only in global reset mode.
MEIE Bit
When the MEIE bit is set to 1 and the MES flag in the GERFLL register is set to 1, an interrupt request is
generated. Modify this bit only in global reset mode.
DEIE Bit
When the DEIE bit is set to 1 and the DEF flag in the GERFLL register is set to 1, an interrupt request is
generated. Modify this bit only in global reset mode.
GSLPR Bit
Setting this bit to 1 places the CAN module in global stop mode.
Clearing this bit to 0 makes the CAN module leave from global stop mode.
Do not modify this bit while the CAN channel is in global operating mode or global test mode.
GMDC[1:0] Bits
These bits are used to select the mode of entire CAN module (global operating mode, global reset mode, or
global test mode). For details, see 18.4.1 Global Modes. Setting the GSLPR bit to 1 in global reset mode
places the CAN module in global stop mode.
