RL78/F13, F14 CHAPTER 12 A/D CONVERTER
R01UH0368EJ0210 Rev.2.10 726
Dec 10, 2015
12.3.10 A/D test register (ADTES)
This register is used to select the + side reference voltage (AV
REFP) or - side reference voltage (AVREFM) of the A/D
converter, or the analog input channel (ANIxx) as the A/D conversion target for the A/D test function.
The ADTES register can be set by an 8-bit memory manipulation instruction.
Reset signal generation clears this register to 00H.
Figure 12-14. Format of A/D Test Register (ADTES)
Address: F0013H After reset: 00H R/W
Symbol 7 6 5 4 3 2 1 0
ADTES 0 0 0 0 0 0 ADTES1 ADTES0
ADTES1 ADTES0 A/D conversion target
0 0 ANIxx (This is specified using the analog input channel specification register (ADS).)
1 0 AVREFM
1 1 AVREFP
Other than the above Setting prohibited
Caution For details of the A/D test function, see CHAPTER 27 SAFETY FUNCTIONS.
