RL78/F13, F14 CHAPTER 34 ELECTRICAL SPECIFICATIONS (GRADE L)

R01UH0368EJ0210 Rev.2.10 1726

Dec 10, 2015

34.6.5 POR Circuit Characteristics

(TA = -40 to +105C, VSS = EVSS0 = EVSS1 = 0 V)

Parameter Symbol Conditions MIN. TYP. MAX. Unit

Detection voltage

Note

POR Power supply rise time 1.48 1.56 1.62 V

VPDR Power supply fall time 1.47 1.55 1.61 V

Minimum pulse width TPW 300

µs



Detection delay time TPD 350

µs



Note This indicates the POR circuit characteristics, and normal operation is not guaranteed under the condition of less

than lower limit operation voltage (2.7 V).
