RL78/F13, F14 CHAPTER 17 LIN/UART MODULE (RLIN3)
R01UH0368EJ0210 Rev.2.10 1234
Dec 10, 2015
Table 17-21. Baud Rate Setting for UART Reception in SNOOZE Mode
(LIN communication clock source = 32 MHz  2%, FRQSEL4 = 0)
UART Baud Rate
(target)
Prescaler
LPRS[2:0]
Baud Rate Generators 0
and 1
LBRP0 and LBRP1
Maximum Allowable
Value
Minimum Allowable
Value
1200 bps 1/2 828 2.45% -2.50%
2400 bps 1/2 412 2.07% -2.30%
4800 bps 1/2 203 1.81% -1.42%
Table 17-22. Baud Rate Setting for UART Reception in SNOOZE Mode
(LIN communication clock source = 24 MHz  2%, FRQSEL4 = 0)
UART Baud Rate
(target)
Prescaler
LPRS[2:0]
Baud Rate Generators 0
and 1
LBRP0 and LBRP1
Maximum Allowable
Value
Minimum Allowable
Value
1200 bps
1/2
621 2.41% -2.55%
2400 bps
1/2
308 2.31% -2.08%
4800 bps
1/2
152 1.81% -1.45%
Table 17-23. Baud Rate Setting for UART Reception in SNOOZE Mode
(LIN communication clock source = 32 MHz  2%, FRQSEL4 =1)
UART Baud Rate
(target)
Prescaler
LPRS[2:0]
Baud Rate Generators 0
and 1
LBRP0 and LBRP1
Maximum Allowable
Value
Minimum Allowable
Value
1200 bps
1/2
826 2.23% -2.26%
2400 bps
1/2
410 1.65% -1.83%
Table 17-24. Baud Rate Setting for UART Reception in SNOOZE Mode
(LIN communication clock source = 24 MHz  2%, FRQSEL4 =1)
UART Baud Rate
(target)
Prescaler
LPRS[2:0]
Baud Rate Generators 0
and 1
LBRP0 and LBRP1
Maximum Allowable
Value
Minimum Allowable
Value
1200 bps 1/2 619 2.28% -2.23%
2400 bps 1/2 307 1.73% -1.76%
Remarks 1. The maximum and minimum allowable values are applied to the baud rates for UART reception. Set the
parameters so that the baud rates for UART transmission should also fall within the allowable range.
2. The receive data length is 8 bits + a parity bit.
3. The numbers in the table are for sixteen samples per bit (i.e. when NSPB[3:0] = 0000b or 1111b).
