RL78/F13, F14 CHAPTER 17 LIN/UART MODULE (RLIN3)
R01UH0368EJ0210 Rev.2.10 1254
Dec 10, 2015
Table 17-29. Examples of Baud Rate Generation (19200 bps, 10417 bps, 9600 bps and 2400 bps) in
LIN Slave Mode [Fixed Baud Rate]
LIN
communication
clock source
Prescaler
Baud rate generator 0-1
N+1 frequency-divided
Baud rate Error
32 MHz 1/1 104 19230.77 +0.16%
192 10416.67 -0.003%
208 9615.38 +0.16%
833 2400.96 +0.04%
24 MHz 1/1 78 19230.77 +0.16%
144 10416.67 -0.003%
156 9615.38 +0.16%
625 2400 0%
16 MHz 1/1 52 19230.77 +0.16%
96 10416.67 -0.003%
104 9615.38 +0.16%
417 2398.08 -0.08%
12 MHz 1/1 39 19230.77 +0.16%
72 10416.67 -0.003%
78 9615.38 +0.16%
313 2396.17 -0.16%
8 MHz 1/1 26 19230.77 +0.16%
48 10416.67 -0.003%
52 9615.38 +0.16%
208 2403.85 +0.16%
Remark The numbers in the table are for sixteen samples per bit (i.e. when NSPB[3:0] = 0000b or 1111b).
