RL78/F13, F14 CHAPTER 21 INTERRUPT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 1476

Dec 10, 2015

Table 21-1. Interrupt Source List (2/4)

Interrupt

Type

Default Priority

Note 1

Interrupt Source

Internal/

External

Vector

Table

Address

Basic Configuration

Type

Note 2

80, 100-pin

64-pin

48-pin

32-pin

30-pin

20-pin

Name Trigger

Maskable 17 INTSTLIN0

STA/

INTLIN0

LIN0 reception status/LIN0

interrupt

Internal 0026H (A)      

18 INTIICA0

IICA0 transfer end

0028H  

Note 3



Note 3



Note 3

 

19 INTP8

Note 6

Pin input edge detection 8 External 002AH (B)  

Note 3



Note 3

  

INTRTC

Note 6

RTC pretimed signal or alarm

match detection

Internal (A)      

20 INTTM00 End of timer channel 0

count/capture

002CH      

21 INTTM01 End of timer channel 1

count/capture

002EH      

22 INTTM02 End of timer channel 2

count/capture

0030H      

23 INTTM03 End of timer channel 3

count/capture

0032H      

24 INTAD End of A/D conversion 0034H      

25 INTP6

Note 4

Pin input edge detection 6 External 0036H (B)      

INTTM11H Upper 8-bit interval timer

interrupt of TAU1 channel 1

(when 8-bit timer function is

selected)

Internal (A)  

Note 3



Note 3



Note 3



Note 3



26 INTP7

Note 4

Pin input edge detection 7 External 0038H (B)      

INTTM13H Upper 8-bit interval timer

interrupt of TAU1 channel 3

(when 8-bit timer function is

selected)

Internal (A)  

Note 3



Note 3



Note 3



Note 3



27 INTP9

Note 4

Pin input edge detection 9 External 003AH (B)  

Note 3



Note 3

  

INTTM01H Upper 8-bit interval timer

interrupt of TAU0 channel 1

(when 8-bit timer function is

selected)

Internal (A)      

28 INTP10

Note 4

Pin input edge detection 10 External 003CH (B)  

Note 3

   

INTTM03H Upper 8-bit interval timer

interrupt of TAU0 channel 3

(when 8-bit timer function is

selected)

Internal (A)      

29 INTST1/

INTCSI10/

INTIIC10

UART1 transmission transfer

end or buffer empty

interrupt/CSI10 transfer end or

buffer empty interrupt

/IIC10

transfer end

003EH  

Note 3



Note 3



Notes 3, 5



Notes 3, 5


