RL78/F13, F14 CHAPTER 21 INTERRUPT FUNCTIONS
R01UH0368EJ0210 Rev.2.10 1493
Dec 10, 2015
Figure 21-3. Format of Interrupt Mask Flag Registers (MK0L, MK0H, MK1L, MK1H, MK2L, MK2H, MK3L)
A
ddress: FFFE4H After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
MK0L PMK5
CMPMK0
PMK4
SPMMK
PMK3 PMK2 PMK1 PMK0 LVIMK WDTIMK
A
ddress: FFFE5H After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
MK0H LIN0TRMMK RAMMK TRJMK0 TRDMK1 TRDMK0 SRMK0
CSIMK01
IICMK01
STMK0
CSIMK00
IICMK00
CLMMK
PMK13
A
ddress: FFFE6H After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
MK1L TMMK03 TMMK02 TMMK01 TMMK00 PMK8
RTCMK
IICAMK0 LIN0STAMK
LIN0MK
LIN0RVCMK
A
ddress: FFFE7H After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
MK1H
TMMK04 SRMK1
CSIMK11
IICMK11
STMK1
CSIMK10
IICMK10
PMK10
TMMK03H
PMK9
TMMK01H
PMK7
TMMK13H
PMK6
TMMK11H
ADMK
A
ddress: FFFD4H After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
MK2L
CAN0CFRM
K
CAN0WUPM
K
CAN0ERRM
K
KRMK PMK11
LIN0WUPMK
TMMK07 TMMK06 TMMK05
A
ddress: FFFD5H After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
MK2H FLMK TMMK13 TMMK12 TMMK11 TMMK10
CANGERRM
K
CANGRF
RMK
CAN0TRMM
K
A
ddress: FFFD6H After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
MK3L TMMK17 TMMK16 TMMK15 TMMK14 LIN1STAMK
LIN1MK
LIN1RVCMK LIN1TRMMK PMK12
LIN1WUPMK
MKxx Interrupt servicing control
0 Interrupt servicing enabled
1 Interrupt servicing disabled
Caution The above is the bit layout for the 100-pin. The available bits differ depending on the
product. For details about the bits available for each product, see Table 21-2. Be sure
to set bits that are not available to 1.
