RL78/F13, F14 CHAPTER 33 INSTRUCTION SET
R01UH0368EJ0210 Rev.2.10 1664
Dec 10, 2015
Table 33-5. Operation List (4/18)
Notes 1. Number of CPU clocks (f
CLK) when the internal RAM area, SFR area, or extended SFR area is accessed, or
when no data is accessed.
2. Number of CPU clocks (f
CLK) when the program memory area is accessed.
3. Except rp = AX
Remark Number of clock is when program exists in the internal ROM (flash memory) area. If fetching the instruction from
the internal RAM area, the number becomes double number plus 3 clocks at a maximum.
Instruction
Group
Mnemonic Operands Bytes Clocks Clocks Flag
Note 1 Note 2 Z AC CY
8-bit data
transfer
XCH A, [HL+B] 2 2

A  (HL+B)
A, ES:[HL+B] 3 3

A  ((ES, HL)+B)
A, [HL+C] 2 2

A  (HL+C)
A, ES:[HL+C] 3 3

A  ((ES, HL)+C)
ONEB A 1 1

A  01H
X 1 1

X  01H
B 1 1

B  01H
C 1 1

C  01H
!addr16 3 1

(addr16)  01H
ES:!addr16 4 2

(ES, addr16)  01H
saddr 2 1

(saddr)  01H
CLRB A 1 1

A  00H
X 1 1

X  00H
B 1 1

B  00H
C 1 1

C  00H
!addr16 3 1

(addr16)  00H
ES:!addr16 4 2

(ES,addr16)  00H
saddr 2 1

(saddr)  00H
MOVS [HL+byte], X 3 1

(HL+byte)  X × ×
ES:[HL+byte], X 4 2

(ES, HL+byte)  X × ×
16-bit
data
transfer
MOVW rp, #word 3 1

rp  word
saddrp, #word 4 1

(saddrp)  word
sfrp, #word 4 1

sfrp  word
AX, rp
Note 3
1 1

AX  rp
rp, AX
Note 3
1 1

rp  AX
AX, !addr16 3 1 4 AX  (addr16)
!addr16, AX 3 1

(addr16)  AX
AX, ES:!addr16 4 2 5 AX  (ES, addr16)
ES:!addr16, AX 4 2

(ES, addr16)  AX
AX, saddrp 2 1

AX  (saddrp)
saddrp, AX 2 1

(saddrp)  AX
AX, sfrp 2 1

AX  sfrp
sfrp, AX 2 1

sfrp  AX
