RL78/F13, F14 CHAPTER 36 ELECTRICAL SPECIFICATIONS (GRADE Y)

R01UH0368EJ0210 Rev.2.10 1797

Dec 10, 2015

A = -40 to +150C, 2.7 V  EVDD0 = EVDD1 = VDD  5.5 V, VSS = EVSS0 = EVSS1 = 0 V) (3/3)

Items Symbol Conditions MIN. TYP. MAX. Unit

Supply

current

Notes 1,

ISNOZ SNOOZE mode

A/D

comparator

operation

During mode transition 1.0 1.3 mA

During

conversion

Low-voltage mode

REFP = VDD = 5.0 V

2.1 2.6 mA

DTC operation 4.5 mA

Notes 1. Total current flowing into VDD and EVDD0, including the input leakage current flowing when the level of the

input pin is fixed to V

DD, EVDD0, VSS, or EVSS0. However, not including the current flowing into the I/O buffer and

on-chip pull-up/pull-down resistors.

2. The values below the MAX. column include the STOP leakage current.
