RL78/F13, F14 CHAPTER 3 CPU ARCHITECTURE
R01UH0368EJ0210 Rev.2.10 153
Dec 10, 2015
Table 3-6. Extended SFR (2nd SFR) List (2/32)
Address Special Function Register (2nd SFR) Name Symbol R/W Manipulable Bit Range After reset
1-bit 8-bit 16-bit
F005CH Port output mode register 12 POM12 R/W
– 00H
F0067H Port mode control register 7 PMC7 R/W
– FFH
F0069H Port mode control register 9 PMC9 R/W
– FFH
F006CH Port mode control register 12 PMC12 R/W
– FFH
F0070H Noise filter enable register 0 NFEN0 R/W
– 00H
F0071H Noise filter enable register 1 NFEN1 R/W
– 00H
F0072H Noise filter enable register 2 NFEN2 R/W
– 00H
F0073H Input switch control register ISC R/W
– 00H
F0074H Timer input select register 0 TIS0 R/W –
– 00H
F0075H Timer input select register 1 TIS1 R/W –
– 00H
F0076H A/D port configuration register ADPC R/W –
– 00H
F0077H Port mode select register PMS R/W
– 00H
F0078H
Invalid memory access detection control
register
IAWCTL R/W –
– 00H
F0079H Interrupt source determination flag register 0 INTFLG0 R/W –
– 00H
F007AH Timer input select register 2 TIS2 R/W –
– 00H
F007BH LIN channel select register LCHSEL R/W –
– 00H
F007CH Interrupt mask register INTMSK R/W –
– FFH
F0090H Data flash control register DFLCTL R/W
– 00H
F00A0H High-speed on-chip oscillator trimming register HIOTRM R/W –
–
Note
F00A8H
High-speed on-chip oscillator frequency select
register
HOCODIV R/W –
– Undefined
F00D8H SPM control register SPMCTRL R/W –
– 00H
F00DAH SP overflow address setting register SPOFR R/W – –
FFFEH
F00DBH
F00DCH SP underflow address setting register SPUFR R/W – –
0000H
F00DDH
F00F0H Peripheral enable register 0 PER0 R/W
– 00H
F00F3H Operation speed mode control register OSMC R/W –
– 00H
F00FEH BCD correction result register BCDADJ R –
– Undefined
F0100H Serial status register 00 SSR00L SSR00 R –
0000H
F0101H – – –
F0102H Serial status register 01 SSR01L SSR01 R –
0000H
F0103H – – –
F0104H Serial flag clear trigger register 00 SIR00L SIR00 R/W –
0000H
F0105H – – –
F0106H Serial flag clear trigger register 01 SIR01L SIR01 R/W –
0000H
F0107H – – –
Note The reset value differs for each chip.
