RL78/F13, F14 CHAPTER 37 PACKAGE DRAWING

R01UH0368EJ0210 Rev.2.10 1835

Dec 10, 2015

37.4 48-pin products

37.4.1 48-pin LQFP

JEITA Package Code RENESAS Code Previous Code MASS (TYP.) [g]

P-LFQFP48-7x7-0.50 PLQP0048KF-A P48GA-50-8EU-1 0.16

Sxb

0.145

+0.055

–0.045

(UNIT:mm)

ITEM DIMENSIONS

7.00±0.20

9.00±0.20

1.60 MAX.

0.10±0.05

1.40±0.05

0.25

0.50

0.08

0.75

0.50

0.60±0.15

1.00±0.20

3°

+5°

–3°

NOTE

Each lead centerline is located within 0.08 mm of

its true position at maximum material condition.

detail of lead end

0.22±0.05
