RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 218

Dec 10, 2015

Figure 4-11. Block Diagram of P16

PORT

PU16

P16

P-ch

PU1

PM1

POM16

POM1

POM

PM16

CMOS

(Schmitt3)

TTL

PIM1

PIM16

PIM

PITHL1

PITHL16

PITHL

CMOS

(Schmitt1)

PMS

PMS0

Alternate function

TO02/TRDIOC1

Alternate function

SDA00

P16/TI02/TO02

TRDIOC1/SI00/

SDA00/RXD0/

TOOLRXD

Alternate function

Internal bus

Selector

Output latch

P1: Port register 1

PU1: Pull-up resistor option register 1

PM1: Port mode register 1

PIM1: Port input mode register 1

POM1: Port output mode register 1

PMS: Port mode select register

PITHL1: Port input threshold control register 1

RD: Read signal

WRxx: Write signal
