RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS
R01UH0368EJ0210 Rev.2.10 258
Dec 10, 2015
Table 4-11. Settings of Registers When Using Port 7 (2/2)
Pin Name PM7x PIM7x POM7x PMC7x PITHL7x
Alternate Function
Setting
Remark
Name I/O
P75 Input 1 – – – 0 × CMOS input
(Schmitt1 input)
1 × CMOS input
(Schmitt3 input)
Output 0 – – – × ×
P76 Input 1 – – – 0 × CMOS input
(Schmitt1 input)
1 × CMOS input
(Schmitt3 input)
Output 0 – – – × (SCK10 output = 1
Note 4
)
P77 Input 1 – – – 0 × CMOS input
(Schmitt1 input)
1 × CMOS input
(Schmitt3 input)
Output 0 – – – × ×
Notes 1. When a pin sharing the serial array unit function is to be used as a general-purpose port pin, the SOmn bit
of the serial output register m (SOm), the SOEmn bit of the serial output enable register m (SOEm), and
the SEmn bit of the serial channel enable status register m (SEm) corresponding to the target unit and
channel must have the same setting as its initial value (m = 0, 1, n = 0, 1).
2. When a pin sharing a timer output function of the timer array unit is to be used as a general-purpose port
pin, the TOmn bit of the timer output register m (TOm) and the TOEmn bit of the timer output enable
register m (TOEm) corresponding to the target unit and channel must have the same setting as in the initial
state (m = 0, 1, n = 0 to 7).
3. When a pin sharing the SNOOZE status output function is to be used as a general-purpose port pin, the
OUTEN0 to OUTEN7 bits of the SNOOZE status output control registers 0, 1, 2, 3 (PSNZCNT0, 1, 2, 3)
must have the same setting as its initial value.
4. When a pin sharing the serial array unit function is to be used as a general-purpose port pin, the CKOmn
bit of the serial output register m (SOm), the SOEmn bit of the serial output enable register m (SOEm), and
the SEmn bit of the serial channel enable status register m (SEm) corresponding to the target unit and
channel must have the same setting as its initial value (m = 0, 1, n = 0, 1).
5. When a pin sharing the serial data output function of the CAN is to be used as a general-purpose port pin,
operation of the corresponding CAN must be stopped.
6. Functions in parentheses can be assigned via settings in the peripheral I/O redirection register 4 (PIOR4).
Remark ï‚´: Don't care
PM7x: Port mode register 7
PIM7x: Port input mode register 7
POM7x: Port output mode register 7
PMC7x: Port mode control register 7
PITHL7x: Port input threshold control register 7
To Next Page
