RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS
R01UH0368EJ0210 Rev.2.10 309
Dec 10, 2015
Table 4-26. Port Configuration of Group A Products (64-pin products) (3/4)
Port
Name
Port Bit
Output
Latch
I/O Mode
Control
Pull-up
Control
Input Type
Control
Output
Type
Control
Operating
Mode
Control
Input
Threshold
Control
PORT8 0 P8.0 PM8.0     
1 P8.1 PM8.1
    
2 P8.2 PM8.2
    
3 P8.3 PM8.3
    
4 P8.4 PM8.4
    
5 P8.5 PM8.5
    
6 P8.6 PM8.6
    
7 P8.7 PM8.7
    
PORT9 0 P9.0 PM9.0     
1 P9.1 PM9.1     
2 P9.2 PM9.2 PU9.2    
3 P9.3 PM9.3 PU9.3    
4 P9.4 PM9.4 PU9.4    
5 P9.5 PM9.5 PU9.5    
6 P9.6 PM9.6 PU9.6    
7       
PORT10 0       
1       
2       
3       
4       
5       
6       
7       
PORT11 0       
1       
2       
3       
4       
5       
6       
7       
PORT12 0 P12.0 PM12.0 PU12.0  POM12.0  
1 P12.1      
2 P12.2      
3 P12.3      
4 P12.4      
5 P12.5 PM12.5 PU12.5 PIM12.5   PITHL12.5
6       
7       
Remark : Not provided.
