RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS
R01UH0368EJ0210 Rev.2.10 316
Dec 10, 2015
Table 4-28. Port Configuration of Group E Products (100-pin products) (2/4)
Port
Name
Port Bit
Output
Latch
I/O Mode
Control
Pull-up
Control
Input Type
Control
Output
Type
Control
Operating
Mode
Control
Input
Threshold
Control
PORT5 0 P5.0 PM5.0 PU5.0    PITHL5.0
1 P5.1 PM5.1 PU5.1
   
2 P5.2 PM5.2 PU5.2
  
PITHL5.2
3 P5.3 PM5.3 PU5.3
  
PITHL5.3
4 P5.4 PM5.4 PU5.4 PIM5.4
 
PITHL5.4
5 P5.5 PM5.5 PU5.5
   
6 P5.6 PM5.6 PU5.6
   
7 P5.7 PM5.7 PU5.7
   
PORT6 0 P6.0 PM6.0 PU6.0  POM6.0  PITHL6.0
1 P6.1 PM6.1 PU6.1  POM6.1  PITHL6.1
2 P6.2 PM6.2 PU6.2 PIM6.2 POM6.2  PITHL6.2
3 P6.3 PM6.3 PU6.3 PIM6.3 POM6.3  PITHL6.3
4 P6.4 PM6.4 PU6.4    
5 P6.5 PM6.5 PU6.5    
6 P6.6 PM6.6 PU6.6    
7 P6.7 PM6.7 PU6.7    
PORT7 0 P7.0 PM7.0 PU7.0 PIM7.0 POM7.0 PMC7.0 PITHL7.0
1 P7.1 PM7.1 PU7.1 PIM7.1 POM7.1 PMC7.1 PITHL7.1
2 P7.2 PM7.2 PU7.2  POM7.2 PMC7.2 
3 P7.3 PM7.3 PU7.3 PIM7.3  PMC7.3 PITHL7.3
4 P7.4 PM7.4 PU7.4   PMC7.4 
5 P7.5 PM7.5 PU7.5    PITHL7.5
6 P7.6 PM7.6 PU7.6    PITHL7.6
7 P7.7 PM7.7 PU7.7    PITHL7.7
PORT8 0 P8.0 PM8.0     
1 P8.1 PM8.1     
2 P8.2 PM8.2     
3 P8.3 PM8.3     
4 P8.4 PM8.4     
5 P8.5 PM8.5     
6 P8.6 PM8.6     
7 P8.7 PM8.7     
PORT9 0 P9.0 PM9.0     
1 P9.1 PM9.1     
2 P9.2 PM9.2     
3 P9.3 PM9.3     
4 P9.4 PM9.4     
5 P9.5 PM9.5     
6 P9.6 PM9.6     
7 P9.7 PM9.7     
Remark : Not provided.
To Next Page
