RL78/F13, F14
CHAPTER 4 PORT FUNCTIONS
R01UH0368EJ0210 Rev.2.10
318
Dec 10, 2015
Table 4-28. Port Configuration of Gr
oup E Products (100-pi
n products) (4/4)
Port
Name
Port Bit
Output
Latch
I/O Mode
Control
Pull-up
Control
Input Type
Control
Output
Type
Control
Operating
Mode
Control
Input
Threshold
Control
PORT15 0
P15.0
PM15.0
PU15.0



PITHL15.0
1 P15.1
PM15.1
PU15.1




2 P15.2
PM15.2
PU15.2



PITHL15.2
3 P15.3
PM15.3
PU15.3



PITHL15.3
4 P15.4
PM15.4
PU15.4




5 P15.5
PM15.5
PU15.5




6 P15.6
PM15.6
PU15.6




7 P15.7
PM15.7
PU15.7




Remark

: Not provided.
349
