RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS
R01UH0368EJ0210 Rev.2.10 351
Dec 10, 2015
Table 4-29. Settings of Port Mode Register and Output Latch When Using Alternate Function (3/8)
Pin Name Alternate Function PIORXX POMXX PMCXX PMXX PXX PIMXX PITHLXX
Function
Name
I/O
P16 TI02 Input 0 × – 1 × 0 0/1
SI00 Input 0 × – 1 × 0/1 0/1
TRDIOC1 Input × × – 1 × 0 0/1
Output × 0 – 0 0 × ×
TO02 Output 0 0 – 0 0 × ×
SDA00 I/O 0 1 – 0 1 0/1 0/1
RXD0 Input 0 × – 1 × 0/1 0/1
P17 TI00 Input 0 × – 1 × 0 0/1
INTP3 Input 0 × – 1 × 0 0/1
TRDIOB1 Input × × – 1 × 0 0/1
Output × 0 – 0 0 × ×
SCK00 Input 0 × – 1 × 0/1 0/1
Output 0 0/1 0 1 × ×
SCL00 Output 0 0/1 – 0 1 × ×
TO00 Output 0 0 – 0 0 × ×
P30 TI01 Input 0 – – 1 × 0 0/1
INTP2 Input 0 – – 1 × 0 0/1
TRDIOD1 Input × – – 1 × 0 0/1
Output × – – 0 0 × ×
SSI00 Input 0 – – 1 × 0/1 0/1
TO01 Output 0 – – 0 0 × ×
SNZOUT0 Output 0 – – 0 0 × ×
P31 TI14 Input 0 – – 1 × – –
TO14 Output 0 – – 0 0 – –
STOPST Output × – – 0 0 – –
(INTP2) Input 1 – – 1 × – –
P32 TI16 Input 0 – – 1 × – –
INTP7 Input 0 – – 1 × – –
TO16 Output 0 – – 0 0 – –
P33 ANI00 Input × – – 1 × – –
AVREFP Input × – – 1 × – –
P34 ANI01 Input × – – 1 × – –
AVREFM Input × – – 1 × – –
Remarks 1. ï‚´: Don't care
PIORxx: Peripheral I/O redirection register
POMxx: Port output mode register
PMCxx: Port mode control register
PMxx: Port mode register
Pxx: Port output latch
2. The relationship between pins and their alternate functions shown in this table indicates the relationship
when a 100-pin product is used. In other products, alternate functions might be assigned to different
pins, but even in this case, the PIORxx, POMxx, PMCxx, PMxx, and Pxx set in the same way.
3. Functions in parentheses in the above table can be assigned via settings in the peripheral I/O
redirection register (PIOR).
(The notes are described after the last table.)
