RL78/F13, F14 CHAPTER 2 PIN FUNCTIONS
R01UH0368EJ0210 Rev.2.10 66
Dec 10, 2015
Table 2-4. List of RL78/F13 (LIN incorporated) Pins Other than Port Pins (3/4)
Pin
Function
I/O Function Pin Count
80-pin 64-pin 48-pin 32-pin 30-pin 20-pin
SCK10
I/O Clock input/output for CSI10
Note 1
Note 1
SCK11
I/O Clock input/output for CSI11
Note 1
Note 1
SI00 Input Serial data input to CSI00
SI01 Input Serial data input to CSI01
SI10
Input Serial data input to CSI10
Note 1
Note 1
SI11
Input Serial data input to CSI11
Note 1
Note 1
SO00 Output Serial data output from CSI00
SO01 Output Serial data output from CSI01
SO10
Output Serial data output from CSI10
Note 1
Note 1
SO11
Output Serial data output from CSI11
Note 1
Note 1
SSI00 Input Slave select input to CSI00 (SPI00)
SSI01 Input Slave select input to CSI01 (SPI01)
SSI10
Input Slave select input to CSI10 (SPI10)
Note 1
Note 1
SSI11
Input Slave select input to CSI11 (SPI11)
Note 1
Note 1
LRXD0 Input Serial data input to LIN
LTXD0 Output Serial data output from LIN
INTP0 Input External interrupt input
INTP1 Input
INTP2 Input
INTP3 Input
INTP4 Input
INTP5 Input
INTP6 Input
INTP7 Input
INTP8 Input
Note 1
Note 1
INTP9 Input
Note 1
Note 1
INTP10 Input
Note 1
INTP11 Input
Note 1
PCLBUZ0 Output Clock output/buzzer output 0
RESOUT Output Reset output
STOPST Output STOP status output
SNZOUT0 Output SNOOZE status output
SNZOUT1 Output
SNZOUT2 Output
SNZOUT3 Output
SNZOUT4 Output
SNZOUT5 Output
SNZOUT6 Output
SNZOUT7 Output
RTC1HZ Output Real-time clock correction clock (1 Hz) output
Note 1. Provided only in the products with 96 Kbytes or 128 Kbytes of ROM.
