VisualMotion 9 Troubleshooting Guide Monitoring and Diagnostics 3-39
DOK-VISMOT-VM*-09VRS**-WA02-EN-P
526 SERCOS Multiplex Channel Config, see ext. diag.
Cause:
The SERCOS multiplex channel is enabled by either the selection of the
Drive PLS Fast Write feature or the detection that the AT or MDT has
exceeded the 16-byte limit. 526 SERCOS Multiplex Channel Config,
see ext. diag. is followed by one of the following extended diagnostics
(examples: D%d = D01 for Drive 01, %s = S-0-0258).
Remedy:
Refer to the extended diagnostics for details. Extended diagnostics can
be viewed by selecting Diagnostics ⇒
⇒⇒
⇒ System in VisualMotion Toolkit.
Extended Diagnostic C-0-0124 Description
D%d: Ident %s not supported in S-
370
Through Parameters A-0-0180..182, a
parameter was entered which is not supported
by the SERCOS MDT Multiplex Channel.
D%d: Ident %s not supported in S-
371
Through Parameters A-0-0185 and 186, a
parameter was entered which is not supported
by the SERCOS AT Multiplex Channel.
D%d: Probe not allowed in Single
Axis Mode
With the SERCOS Multiplex Channel enabled,
the Probe option is not available in Single Axis
mode.
D%d: Multiple probe idents in
telegram
With the SERCOS Multiplex Channel enabled,
only one probe ident is allowed in the multiplex
channel.
D%d: PLS Idents cannot be entered
directly by user
The PLS Fast Write feature, A-0-0004 bit 8 set,
automatically addresses the necessary idents
for PLS write in the SERCOS Multiplex Channel.
Maximum Quantity of Multiplex
Drives Exceeded
The limit of how many drives the GPP control
can support with the SERCOS Multiplex
Channel enabled has been exceeded.
Table 3-9: SERCOS Multiplex Channel Extended Diagnostics
527 Control Initialization Error, see ext. diag.
Cause:
527 Control Initialization Error, see ext. is followed by an extended
diagnostic, for example: D%d = D01 for Drive 01, %s = S-0-0258.
Extended diagnostics can be viewed by selecting Diagnostics ⇒
⇒⇒
⇒ System
in VisualMotion Toolkit.
Remedy:
Refer to the extended diagnostics for details. Extended diagnostics can
be viewed by selecting Diagnostics ⇒
⇒⇒
⇒ System in VisualMotion Toolkit.
Extended Diagnostic C-0-0124 Description
D%d: Ident %s is not supported in
cyclic channel
The SERCOS Multiplex channel is being
configured and an ident was selected that has
a variable length.
Table 3-10: Control Initialization Extended Diagnostics
