2-8 VisualMotion Tools for Diagnosing VisualMotion 9 Troubleshooting Guide
DOK-VISMOT-VM*-09VRS**-WA02-EN-P
2.2 Using VisualMotion's End User Tool for Diagnosing
VisualMotion's End User Tool is freeware diagnostic software designed to
provide the user with diagnostic information and parameter accessibility in
the following areas:
• Archive and Restore parameters
• Diagnostics for control and drives
• Viewing and editing control, task, axis and SERCOS drive parameters
• Viewing and editing parameters for additional SERCOS devices, such
as I/O
• Ability to create and edit Custom parameter list
• Password Security
Note: The End User Tool installation is included, by default, as part
of the VisualMotion 9 installation. The End User Tool can be
launched from the \\Rexroth\VisualMotion 9 folder, by double
clicking on the EndUserTool.exe file.
End_User_Tool.tif
Fig. 2-10: End User Tool
