VisualMotion 9 Troubleshooting Guide Monitoring and Diagnostics 3-59
DOK-VISMOT-VM*-09VRS**-WA02-EN-P
!62 Cam X data is < 0 or greater than 360
All values in the x-column (right hand column) of the CAM file sent to the
control must be between zero and the modulo value of the master.
!63 X-Column does not start at 0 or end at 360
In the CAM file sent to the control, the first point must be zero and the last
point must be the modulo value of the master. Check the beginning and
end of the CAM file.
!64 Not supported in user prog file version 1.1
The requested feature is not present in the file version of the user
program from which the data was requested or sent. To use this feature,
a compiler upgrade is necessary.
!72 Program does not include a PLS
PLS data was requested from a program that does not support the
Programmable Limit Switch functions or does not have any PLSs
configured.
!73 Invalid ABS or REL point index (%d)
Point %d is zero or is greater than the allocated maximum number of
points for the selected point table.
!74 Error in command execution
A procedure command set in the control or drive parameter has not been
successfully completed.
!75 Comm. port buffer overflow
The serial port received buffer has overflowed. To avoid this error, the
host must communicate in half duplex or use XON-XOFF handshaking
correctly.
!78 Service channel in use
The SERCOS service channel is being used by a user program task or by
an internal process, and has suspended the transmission of a list or text
string. See the description of parameter C-0-0010 bit 12.
!79 PID block number does not exist
This error is issued when the selected PID block is not initialized in the
user program.
