004 Tray-4 [–9~ +9/ +2.0 mm / 0.1 mm/step]
005 Duplex Tray [–9 ~ +9/ +0.0 mm / 0.1 mm/step]
006 Bypass Tray [–9 ~ +9/ +3.0 mm / 0.1 mm/step]
007 LCT [–9 ~ +9/ +1.5 mm / 0.1 mm/step]
1003
Regis Buckle Adj Registration Buckle Adjustment
Adjusts the relay clutch timing at registration. Relay clutch timing determines the amount of paper
buckle at registration. (A “+” setting causes more buckling.)
001 Trays 2,3,4, LCT
[–9 ~+9 / 0 /1 mm step]002 Duplex Tray
003 Bypass Tray
004 Tray-1 [–9 ~+9 / 1 /1 mm step]
005 By-pass Thick [–9 ~+9 / -2 /1 mm step]
1007
By-pass SizeDisp DFU By-pass Feed Paper Size Display
Displays the paper width sensor data for the by-pass feed table. The detected paper size display
is shown as bit settings in an 8-digit display.
(7)1110 0000(0)
1012
Exit Jct. SOLs Exit Junction Solenoid Start Timing
Adjusts the timing of the solenoids at the entrance and exit of the paper exit section to accom-
modate the increased speed of the duplex unit.
This SP has been added to compensate for the increased operation speed of the duplex unit for
this machine. Increase the value if the leading edges are jamming. Decrease the value if trailing
edges are bending at the entrance
001 Exit Start SOL [200 ~ 450 ms / 300 ms /10 ms]
002 Exit End SOL [200 ~ 450 ms / 370 ms /10 ms]
1103
Fusing Idling
Service Program Mode Tables
187
