10/2 = 5 x 10 + 10 = 60. However, the limit is 50 ms so in this case, 60 ms is reduced to 50
ms.
2913
Tst Pattern Den Print Density for Test Pattern
[0 ~ 15 / 15 / 1]
Sets the print density for the patterns printed with SP2-902-3.
2914 Process Ctrl Set Process Control Setting
001
C alpha [0 ~ 400 / 150 / 10V step]
Adjusts the charge roller voltage used when paper with a small width is fed from the by-pass
tray. The paper width below which the correction starts depends on the value of SP2-309-1.
Use this SP when an image problem (such as white spots at the center of black dots or breaks
in thin black lines) occurs when paper with a small width is fed from the by-pass feed tray.
002
C beta [0 ~ 400 / 0 / 10V step]
Adjusts the charge roller voltage used when paper with a small width is fed from the by-pass
tray. The paper width below which the correction starts depends on the value of SP2-309-2.
Use this SP when an image problem (see 2-914-1) occurs when paper with a small width is fed
from the by-pass feed tray.
003
B gamma [0 ~ 300 / 200 / 10V step]
Adjusts the development bias used when paper with a small width is fed from the by-pass tray.
The paper width below which the correction starts depends on the value of SP2-309-1.
Use this SP when an image problem (see 2-914-1) occurs when paper with a small width is fed
from the by-pass feed tray.
004
B delta [0 ~ 300 / 50 / 10V step]
Adjusts the development bias used when paper with a small width is fed from the by-pass tray.
The paper width below which the correction starts depends on the value of SP2-309-2.
Use this SP when an image problem (see 2-914-1) occurs when paper with a small width is fed
from the by-pass feed tray.
2920 LD Off Check DFU
2960
Toner Over Sens Toner Overflow Sensor
5. Service Tables
200
