Number Bit Description
Reading
0 1
3 Fusing Unit Detected Not detected
2 Total Counter Not detected Detected
1 Key Counter Detected Not detected
0 Key Card Present Detected Not detected
SP5803-007
Paper End
7 Front cover/open closed Open Closed
6 Vertical feed path Clear Not clear
5 2nd Tray Lift Sensor
Paper not at up-
per limit
Paper at upper limit
4 1st Tray Lift Sensor
Paper not at up-
per limit
Paper at upper limit
3 Lower Relay Sensor Paper detected Paper not detected
2 Upper Relay Sensor Paper detected Paper not detected
1 Lower Paper End Sensor
Paper not detect-
ed
Paper detected
0 Upper Paper End Sensor
Paper not detect-
ed
Paper detected
SP5803-008
DIP Switch
7 Dip Switch - 8 On Off
6 Dip Switch - 7 On Off
5 Dip Switch - 6 On Off
4 Dip Switch - 5 On Off
3 Dip Switch - 4 On Off
2 Dip Switch - 3 On Off
1 Dip Switch - 2 On Off
0 Dip Switch - 1 On Off
SP5803-009
Duplex Unit
7 Not used
Input Check
267
