Replacing the Ink Cartridge

108

Replacing and disposing consumables

Close the Front Cover.

Creati

• The cap removed from the ink cartridge can be kept on

the upper left of the drum.

• Dispose the empty Ink cartridge according to the

regulations in your local community.

NOTE

Ink Cartridge Cap Holder
