Check & Error Display
126
Troubleshooting
When the (Jam) indicator blinks
Check error locations and error numbers (Error Number Display) and take the following procedures:
Location
No.
Error Number Cause Action
A-06
An obstacle exists under the Paper Feed
Tray or on the paper.
Check if any obstacle exists under the Paper Feed Tray or
on the paper. If an obstacle exists, remove it.
The Stripper Unit has been disconnected. Set the Stripper Unit
correctly.
A-02
A master has not been correctly wrapped
around the Print Drum.
1) Pull out the Print Drum slowly, and then remove the
master on the Print Drum.p.114
2) Set the Print Drum into the machine.
3) Open the Master-Making Unit Cover and set the master
again.
4) Close the Master-Making Unit Cover.
5) Perform the master-making operation again.
Contact your dealer (or authorised service representative) if
the error is not cleared.
A-04
A master has not been sent to the Master
Disposal Box.
1) Pull out the Print Drum slowly, and then remove the
master on the Print Drum.p.114
2) Set the Print Drum again.
3) Press the <Start> key.
J-12
A paper jam has occurred around the Print
Drum
1) Pull out the Print Drum slowly.
p.114
2) If you find jammed paper, remove it.
A-16
An unnecessary master remains on the Print
Drum.
1) Pull out the Print Drum and remove the master on the
Print Drum.p.114
2) Set the Print Drum into the machine.
3) Perform the master-making operation again.
A-01
A-34
A master has not been correctly set. Open the Master-Making Unit Cover, remove the Master
Roll, and then set the master correctly. If the master is
loose, turn the right flange inward to correct it, and then
close the Master-Making Unit Cover.
p.109
A-17
A master has not been correctly cut. 1) Remove the Master Roll and close the Master-Making
Unit Cover.
2) Set the master again.
p.109
When you put your hand into the machine to
carry out maintenance work, for example to
remove paper, be careful with hooks and metal
edges inside the machine to avoid injuries.
CAUTION
To Next Page
