46 Rockwell Automation Publication 5032-UM001A-EN-P - April 2023
Chapter 5 Configure the IO-Link Master Module
Table 10 - IO-Link Master Module Definition Parameters
Parameter Definition Available Choices
Series Shows the module hardware series. Module-specific
Revision Shows the module firmware revision, including major and minor revision levels. Module-specific
Electronic Keying
Software method by which you reduce the possibility of using the wrong device in a control
system.
For more information, see the following:
• IO-Link Master Module and IO-Link Device Tag Definitions on page 97
• Electronic Keying in Logix 5000 Control Systems Application Technique,
publication LOGIX-AT001
•Exact Match
• Compatible Module
• Disable Keying
Connection
Determines the following for the module type that you configure:
• Available configuration parameters
• Type of data that is transferred between the module and the controller
• Which tags are generated when configuration is complete
•Data
• Data and Ethernet Status
• Data with Events
• Data with Events and Ethernet Status
IO-Link Event Timestamp Shows the time stamps for IO-Link events.
•Yes
•No
Port Shows the module port numbers. Not configurable
Channel Shows the module channel numbers. Not configurable
IO-Link Class B Enabled Enables Class B for the selected port.
Cleared
Selected
Channel Mode
Shows the mode for the channel.
Power Supply mode is displayed if you select the IO-Link Class B Enabled checkbox.
•Disabled
•IO-Link
• Digital Input
• Digital Input, Timestamp
• Digital Output, Short Circuit
• Digital Output, Group Short Circuit
• Digital Output, Short Circuit, No Load
• Digital Input, Fallback
• Digital Input, Timestamp, Fallback
• Power Supply (not selectable)
Channel Mode Types
Shows the different type of channel modes available for that channel:
• Digital Input (DI)
• Digital Output (DO)
•IO-Link
Not configurable
WARNING: Do not use an output channel as a power supply for Class B devices.
In online mode, only the Electronic Keying and IO-Link Class B Enabled parameters
can be changed.
