Chapter 5 Configure the IO-Link Master Module
Available Connection Types
The Connection choice determines what data is exchanged between the owner-controller and
the module.
Table 11
describes the connection types that you can use with the ArmorBlock 5000 8-channel
IO-Link master module.
For more information on how to use the Module Definition parameters for ArmorBlock 5000
8-channel IO-Link master modules, see the Studio 5000 Logix Designer application online Help.
Table 11 - Connection Types for ArmorBlock 5000 8-channel IO-Link Master Module
Connection Type Description
Data
The module returns the following to the controller:
• General fault data
•Input data
• Counter data
The controller returns the following to the module:
• Output data
Data and Ethernet Status
The module returns the following to the controller:
• General fault data
•Input data
• Counter data
• Ethernet Status data
The controller returns the following to the module:
• Output data
Data with Events
The module returns the following to the controller:
• General fault data
•Input data
• Counter data
• Event input data
The controller returns the following to the module:
• Output data
• Event output data
Data with Events and Ethernet
Status
The module returns the following to the controller:
• General fault data
•Input data
• Counter data
• Ethernet Status data
• Event input data
The controller returns the following to the module:
• Output data
• Event output data
