Appendix A Troubleshoot Your IO-Link Master Module
Module Diagnostics
Figure 9 shows the Module Diagnostics, which provides information on a module-wide basis.
To access the Module Diagnostics, see Module Info View on page 49.
Figure 9 - Module Diagnostics
Port Diagnostics
Figure 10 shows the Port Diagnostics, which provide information on an individual port basis.
To access the Port Diagnostics, see Port Configuration View
on page 57.
Figure 10 - Port Diagnostics
