Roland Fantom G7 User Manual

266
Editing a Sample
1. Press [SAMPLE].
The Sample Edit screen will appear.
fig.14-007_50
Samples that you edit will be lost when you turn off the power.
If you want to keep them, you must Save them (p. 274).
F-key operations in the Sample Edit screen
Parameters in the Sample Edit screen
Here’s how to change the magnification of the sample display.
1. In the Sample Edit screen, press [F6 (Zoom)].
The Zoom window will appear.
2. Use [CURSOR] to change the magnification of the display.
• Horizontal axis (time axis): 1/1–1/65536
Press to increase the display magnification.
Press to decrease the display magnification.
• Vertical axis (waveform amplitude axis): x1–x128
Press to increase the display magnification.
Press to decrease the display magnification.
3. Press [F8 (Close)] to close the window.
Displaying Sample Edit Screen
(Sample Edit)
F-key
Explanation Page
F1
Sample List
Shows the sample list. p. 263
F2
Param
Displays the Sample Parameter screen,
where you can make various settings for
the sample.
p. 268
F3
Modify
Truncate Cuts an unwanted por-
tion
p. 269
Emphasis Boosts/limits the high
frequency range
p. 269
Normalize Maximizes the volume p. 270
Amp Applies a volume enve-
lope
p. 270
Time Stretch Stretches/shrinks the
sample
p. 271
Chop Divides the sample p. 272
F4
Beat
Specifies the start/end point of the sample
in units of a beat.
p. 267
F5
Beat
Specifies the start/end point of the sample
in units of a beat.
p. 267
F6
Zoom
Zooms the waveform display. p. 266
F7
Preview
Auditions the selected sample. –
F8
Exit
Returns to the previous screen. –
Parameter Explanation Page
Start Point The point at which playback will start. p. 267
Loop Start The point at which loop playback (second
time and onwards) will start.
p. 267
End Point The point at which playback will end. p. 267
Zoom Horz The magnification (horizontal axis) of the
display.
p. 266
Zoom Vert The magnification (vertical axis) of the dis-
play.
p. 266
Original
Key
Note number that will play the sample at
the pitch at which it was sampled.
p. 268
BPM Specifies the original tempo of the sample. p. 268
Sample
Gain
Adjusts the gain of the sample. p. 268
Magnifying/Shrinking the
Waveform Display (Zoom)
Even without displaying the Zoom window, you can press
to expand/shrink the horizontal axis, or hold down [SHIFT]
and press to expand/shrink the vertical axis.
Fantom-G_r_e.book 266 ページ ２００９年７月２日 木曜日 午後２時５５分

Roland Fantom G7 Specifications

General

Polyphony	128 voices
MIDI	In, Out, Thru
Keyboard	76 keys
Sound Generator	ARX-based sound engine
Display	8.5-inch wide TFT color LCD
Sequencer	128 tracks
Effects	Chorus: 3 types
USB	USB (Storage, MIDI, Audio)
Audio Inputs	2 x 1/4" (L/Mono, R)
Storage	USB flash drive
