Basic Operation
Printing
45

Press to display the screen on the left.
Press
.
The media is cut o.
You can make the setting in the software RIP for automatic media cuto after printing has nished. For
information on how to make the setting, refer to the documentation of the software RIP you're using.
FUNCTION
SHEET CUT
Printed area
Knife guide
Reflective tape
The media is
moved forward
and cut along this
line.
Cut-off Operations
When the media clamps are attached, the screen on the left appears.
Open the front cover and detach the left and right media clamps
and press
.
 Be sure to detach the media clamps. Performing cuto with the media clamps remaining attached
may cause the operation to be interrupted due to detection of the media clamps.
 If the media clamps are present on the machine when the setting to execute automatic cuto of
the media is made on the RIP software, the media clamps are detected and no cuto operation
is performed.
 Before you're performing cuto, never use
to pull the media back. Unless the end of the
media has been pulled out to a location to the front of the platen, cuto may not be performed
smoothly.
Give Attention to Media Composition
 For some types of media, cuto is not possible.
 Some types of media may remain on the platen after cuto. If the media remains on the platen,
remove it by hand.
REMOVE
MEDIA CLAMPS
