3
Maintenance
Replacing Consumable Parts
69
Replacing the Felt Wiper
The felt wiper is the part used for cleaning of the print heads. When such the screen is displayed on the display
screen, it is the time for replacement. Replace it with a new part.
Regarding the purchase of the felt wiper, contact your authorized Roland DG Corp. dealer or us.
CAUTION
Be sure to perform operations as specied by the following instructions,
and never touch any area not specied in the instructions.
Sudden movement of the machine may cause injury.
1.
Enter the felt wiper replacement menu.
When the screen on the left appears, press .
Remove any media.
Press .
x
Press several times until the screen on the left appears.
Press
, and then twice.
y
Press , and then .
z
Press .
The print-head carriage moves to a location where felt wiper replacement
is possible, and then the screen on the left appears.
TIME FOR
FELT REPLACE
Necessary items
TIME FOR
FELT REPLACE
To Next Page
