Roland VersaEXPRESS RF-640 - Replacing Consumable Parts; Replacing the Wiper

3
Maintenance
66
Replacing Consumable Parts
Replacing the Wiper
The wiper is the part used for cleaning of the print heads. When such the screen is displayed on the display
screen, it is the time for replacement. Replace it with a new part.
Regarding the purchase of the wiper, contact your authorized Roland DG Corp. dealer or us.
CAUTION
Be sure to perform operations as specied by the following instructions,
and never touch any area not specied in the instructions.
Sudden movement of the machine may cause injury.
1. Display the [REPLACE WIPER] menu.

When the screen on the left appears, press .

Remove any media.

Press .
x
Press several times until the screen on the left appears.
Press
, and then twice.
y
Press .
z
Press .
The print-head carriage moves to a location where wiper replacement is
possible, and then the screen on the left appears.
TIME FOR
WIPER REPLACE
Necessary items
TIME FOR
WIPER REPLACE
MENU
SUB MENU
SUB MENU
MAINTENANCE
MAINTENANCE
REPLACE WIPER
OPEN COVER R
Wiper Tweezers
