RTI Barracuda User Manual

2. Description of the Barracuda
Hardware and Specifications
2012-10/4.3A
29
Barracuda & QABrowser Reference Manual
2.6.3 Signal-Extension Module (MP-SEM)
2.6.3.1 General
The Signal Extension module is connected to the Multi-Purpose Module, and cannot
therefore be used separately.
Input and output signals:
· Analogue In
· Analogue Out
· Trig In
· Trig Out
The Analogue In makes it possible to sample a current signal via a LEMO triaxial
connector (e.g. tube current from a MAS probe, light from a L100 light detector, or tube
voltage from a voltage divider).
The Trig In makes it possible to trig the Barracuda from an external signal.
The Analogue Out gives the analogue radiation output measured by the Multi-Purpose
Detector, via a BNC connector attached to the Signal Extension Module.
The Trig Out makes it possible to trig an oscilloscope from the Multi-Purpose Detector.
2.6.3.2 Specifications, MP-SEM
General
Signal
Connector
Signal range
Analogue In
LEMO triaxial connector.
1 nA – 0.05 mA
Analogue Out
BNC out for the radiation output signal measured
with the MPD.
0 – 5 V
Trig In
BNC in for trig of the Barracuda from an external
signal.
Digital levels, 0/5 V
Trig Out
BNC out for trig of an external instrument on the
signal from the MPD.
Digital levels, 0/5 V
(No trig = 0 V, Trig = 5 V)
2.6.4 Electrometer Module (EMM)
2.6.4.1 General
The Electrometer Module have one or two electrometers with a LEMO triaxial
connectors for dose detectors, ionization chambers, mAs probes, or light detectors.
The module measures current, charge, time or pulses, and waveform.
Five different configurations are available:
· EMM-1Ch, single channel electrometer module
· EMM-2Ch, dual channel electrometer module
· EMM-Bias, single channel electrometer module with polarizing voltage (bias)
