2. Description of the Barracuda
Maintenance
2012-10/4.3A
51
Barracuda & QABrowser Reference Manual
2. Remove the side covers.
Start with the side where the
serial connector is located.
3. Use the screwdriver to
push out the pin that locks
the modules.
4. Use the screwdriver (or
better, a plastic pin to avoid
scratches) to carefully pull
out the module that should
be removed.
54
56
