3. Description of the QABrowser
Battery & Power Status
Barracuda & QABrowser Reference Manual
2012-10/4.3A
88
Barracuda system is powered on. For the Palm this should normally always be on.
Barracuda Charging
Make sure that chargeable batteries
are inserted before enabling charging.
Palm Startup Charging
You can select the ability to have the Barracuda charge the Palm from the time the
Barracuda is turned on. This feature means that if the handheld has dead batteries the
Barracuda can still be used to measure. It is not necessary to bring the cradle and
power supply for the handheld.
With this feature a completely dead
handheld can be connected to the
Barracuda and it will start charging as soon
as the Barracuda is turned on. The checkbox
"Enable charging at startup" needs to be
checked, for this to work (default on).
In the figure example you can see that the
charging is on and that the system is set-up
to automatically commence Palm charging
when the Barracuda is powered on.
2: If you have the optional Barracuda serial Bluetooth Module, make sure
the Module is plugged in when powering on the Barracuda. The system
will check for the Bluetooth Module, and it will indicate that it was detected
by 2 flashes with the RTI logo a few seconds after power on. If this does
not work, the checkbox "Enable charging at startup" needs to be checked.
The Barracuda can be powered from a power supply, alkaline batteries, or chargeable
batteries.
If the Barracuda is powered from batteries the following warnings are displayed when
the batteries are low:
