Sakura Histo-Tek VP1 User Manual

1. Operating Procedure
2-12
 Tissue Processing screen
This screen appears when "Immediate Start" is selected
as the tissue processing starting method, or the starting
time arrives in the case of delayed start.
[1] Processing status display area
The status of tissue processing is displayed.
The illustration of the retort shows the step number at
which the instrument is standing by, and the remaining
processing time.
The station number at which the instrument is standing
by, and the solution name are displayed beneath the
retort.
[2] Solution configuration diagram
A solution configuration diagram for the current program
is displayed. The station number, processing time and
solution name are shown at each station.
Each station is shown in the color preregistered for the
solution group. The station where processing is currently
performed is shown in blue.
[3] View/List Selector button
Use this button to change the station configuration
display mode to list. Touching this button again to
change the mode back to station.
[4] Pause button
Touch this button to pause the instrument.
Note
Touching the button displays the Enter Password
window.
Enter a password within 30 seconds; if not, the
Enter Password window will close.
You can pause the instrument once the password
has been accepted.
[5] Predicted Endtime field
The date/time the tissue processing is predicted to end is
shown.
[1]
[2]
[3]
[4]
[5]
