Samsung DVM PLUS III User Manual

III-289
O
UTDOOR
U
NITS
2) RVXVHT140GE / RVXVHT160GE
Oil separator
Low pressure sensorAccumulator
DVI compressor
FVI compressor 1
FVI compressor 2
Liquid tube sensor
4way valve
Ambient air temp. sensor
PWM valve
Liquid bypass
valve
Main EEV 1, 2
High pressure sensor
Turbo intercooler
Hot gas bypass valve
EVI bypass valve
Suction temp. sensor
High pressure switch
Low pressure sensor
EVI EEV
Discharge temp. sensor
EVI_in temp.sensor
Oil valve
Sump(Base)temp. sensor
Oil temp. sensor
Oil service valveLiquid service valve
Low pressure gas service valve
Cond_out temp. sensor
3-1.DVM,HR3_Outdoor(238~293) 3/15/08 1:02 Page 289
