Samsung DVM PLUS III User Manual

V-17
C
ONTROL
S
YSTEMS
Special function display 3
: Displayed when automatic stop function is set.
: Displayed when the wired/wireless remote controller is prohibited by upper-layer devices.
Temperature setting button (applicable only for Cooling, Heating and Auto.)
If is pressed, increase by 1°C (°F). If is pressed, decrease by 1 °C (°F).
Fan speed setting button
Press this button to change the fan speed in the following order Auto->Low->Med->High->Turbo.
Schedule Set / No button
Press this button to enter the schedule setting mode.
During the schedule setting mode, it makes it possible to show an operation schedule status or to set a new schedule with
the button input.
Holiday Apply / Cancel button (only applicable for schedule setting mode)
Press this button to deactivate the operation schedule of the selected number. Press this button again to activate the
operation schedule of the selected number.
Select day button (only applicable for schedule setting mode)
Press this button to change days in the following order: S ➞ M ➞ T ➞ W ➞ T ➞ F ➞ S.
On/Off button (only applicable for schedule setting mode)
Press this button to enter On schedule setting mode. Press this button again to enter Off schedule setting mode.
Hr. Min button (only applicable for schedule setting mode)
Press Hr. button to increase time by 1 hour.
Press Min button briefly to increase time by 1 minute. Give a long press to increase time by 10 minutes.
Mode button
Press this button to change the operation mode in the following way: Cool ->Dry ->Fan -> Heat -> Auto.
Quiet button
Press this button to select the Quiet indoor unit operation.
Swing button
Press this button to change the air flow direction.
Sleep button
Press this button to select the Sleep operation for an indoor unit.
Set button (only applicable for schedule setting mode)
After completing a schedule setting (time, operation mode, fan speed, desired temperature), press this button to store the
schedule.
Cancel/Delete button (only applicable for schedule setting mode)
Press this button briefly to exit the schedule setting mode. Give a long press to delete the set schedule.
Filter replacement alarm reset button
Press this button to clear the filter replacement alarm display.
Temp. button
Press this button to display the room temperature.
Reset button
Press this button briefly to set the current time. Give a long press to change the current time and schedule setting to the
default mode.
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
05-1_control systems(002~045) 3/15/08 4:09 Page 17
