No. Name Description
Digital time display
Displays the current time in the monitoring mode, while displaying schedule time in the
scheduling mode.
Display mode For the scheduling set mode, is displayed. whereas the monitoring mode does not display.
Schedule indication If the scheduler function is being used, it displays (rotation). Otherwise, it displays .
Schedule day Displays the present day and indicates if there is an operation schedule for each day.
Analog watch Displays the On time/ Off time for the specific schedule.
Time adjustment button Press Up/Down buttons to adjusts the operating schedule time and the current time.
Schedule setup button Press this button to enter or exit the schedule setting mode.
Current time button Press this button to set or check the current time (refer to the user manual).
Current day button Press this button to set or check the current day (refer to the user manual).
Reset button
Press this button to delete all schedule settings. At this time, the current time returns to
the default mode.
Return button Press this button to return from the schedule setup mode to the monitoring mode.
Delete button After selecting On or Off time schedule, press this button to cancel the schedule.
Enter button Press this button to confirm the setting.
Off time button Press this button to set or check the Off time schedule.
On time button Press this button to set or check the On time schedule.
Day selection button
Press this button to change and select the days in the following order
➟➟➟
➟➟ ➟
V-41
C
ONTROL
S
YSTEMS
3
4
8
11
7
9
6
14
16
15
5
13
12
1
2
3
4
5
6
7
8
10
11
9
3) Description of buttons and functions
21
12
13
14
15
16
10
