2) Function
(1) S-NET3 function description
View the management structure Control and monitor the indoor units (max. 4,096 units).
View the installation structure
Check and refer the state of various devices such as indoor/outdoor
units, centralized controller, and I/M.
Indoor unit/ERV control
Set the operation mode, temperature, fan speed, and fan
Control & Monitoring direction of indoor unit/ERV.
Indoor unit/ERV monitoring Monitor the status of indoor unit/ERV.
View outdoor unit
Check the outdoor unit’s cycle data and the cycle data of the
linked indoor units.
View DMS Check the status data of the control unit linked to DMS.
Create new schedule Set new schedule.
View schedule Check the schedule of the selected indoor unit.
Start/Stop schedule Start/Stop schedule application.
Schedule
Store/Call schedule Store/Call a prepared schedule.
View daily schedule Confirm each schedule by date.
Set common exception date Set the date which schedule operation is not applied on.
Usage time and power
Check the usage time and power for total, group, and individual
indoor units.
Power consumption report
For preparing the report on the power consumption by each indoor
unit for the period set.
Usage time and power
Power distribution management
Edit an indoor unit’s power management structure
group edition
Set the electricity rate section Set up to 3 sections for electricity billing management.
Indoor unit status
Check the status of indoor unit operation / temperature setting
per period.
Usage time and power
Check the usage time and power for total, group, and individual
Statistics and analysis
indoor units.
Indoor unit usage The usage ratio of all indoor units for a specific period.
Set environment
Set the environment related to S-NET3
(password, language, temperature unit).
Set DMS Set the DMS to connect with S-NET3.
System management Refer event log Refer the warning, error, data of indoor units.
Renew installed device information Modify S-NET3 data if installation data has been changed.
DMS backup/restore Backup the data of DMS connected to S-NET3.
S-NET3 backup/restore Backup the data of S-NET3.
