3-2. S-NET3 (MST-P3P)
(2) Detailed S-NET3 function description
• Monitor the operation status of max.16 DMS units, and max. 4,096 indoor units.
•
Monitor the status of indoor/outdoor units, controllers connected to S-NET3.
• Monitor the power consumption and usage time of the indoor/outdoor units connected to S-NET3.
• Monitor the power consumption of indoor units.
➊
Operation status monitoring
• Able to monitor the indoor unit’s operation status, current temperature, setting temperature,
operation mode, restriction on remote control use.
• Operation color.
❷
Indoor/Outdoor units’ cycle data monitoring
• Able to refer to the status of indoor/outdoor units, and controllers.
• Able to refer to the cycle data of the indoor/outdoor units.
(Compressor status, high pressure, low pressure, discharge temperature, etc.)
• Able to check the program version of the indoor/outdoor units, controllers.
❸
Power consumption and usage time monitoring
• Able to refer to power consumption of each indoor unit and group.
•
Able to refer to the power consumption by grouping indoor units to be managed together with the
power structure edit.
• Able to refer to indoor unit usage time by date and period as well as the use ratio.
• Able to refer to sectional power consumption by dividing power distribution sections into three.
(requires default setting)
• Able to monitor the operation status, mode, fan speed of the ERV.
•
Able to monitor max. 4,096 indoor units and ERVs.
• Able to adjust the installation structure to the convenience of administrators with its structure edit
function. (by floor, by name, etc.)
Blue
On
Gray
Off
Black
Filter
replacement
Yellow
Defrost
operation
Purple
Network
error
Red
Error
