Operation
Fig. 1-2
1
MOTOR LOADING
2
GEAR LOADING
3
SWITCH MODE
4
GEAR CAM MAIN
5
LEVER CAM
6
DRUM
7
MOTOR CAPSTAN
8
GEAR CAPSTAN
9
SLIDER MAIN
0
BELT TIMING
A
LEVER EJECT
B
GEAR PULLEY
C
HOLDER FPC SUB
1
2
3
4
5
C
6
7
8
9
0
A
B
