Operation
1-3 Operation Description
Fig. 1-4
2 GEAR WHEEL MOTOR
MOTOR LOADING 1
GEAR WORM LOADING 3
GEAR LOADING 4
SWITCH MODE 5
GEAR CAM MAIN 6
1-3-1 Gear Train
Motor Loading 1 rotates.
(Gear Wheel Motor 2 Gear Worm Loading 3 )
↓
Gear Loading 4 rotates.
↓
Switch Mode 5 rotates.
↓
Gear Cam Main 6 rotates.
