Samsung Electronics3-8

Disassembly and Reassembly

3-1-8 Ass’y Rear Board Removal

REMOVE THE REAR ASS’Y

IN THE DIRECTION OF

ARROW.

REMOVE 2 SCREWS.

Fig. 3-8 Ass’y Rear Board Removal
